CCPS32 Ceramic Endress Hauser Pressure Sensor Capacitive Corrosion Resistant

  • 1
  • 2

Brand Name : Endress+Hauser

Model Number : CCPS32/UCS2

Place of Origin : Germany

MOQ : 10

Price : USD/CNY

Payment Terms : T/T

Certification : HART

Supply Ability : 10000PCS / Month

Delivery Time : 5-8 workdays

Packaging Details : Carton packing

Brand : Endress+Hauser

Material : Capacitive Ceramic

Contact Now

Endress+Hauser CCPS32 Capacitive Ceramic Pressure Sensor

Performance
  • Basic ceramic material

- Extremely high overload limit

- Absolutely resistant to wear

- High temperature stability

- High long-term stability

- No hysteresis

- Corrosion-resistant

  • Active electronic
-Sensor-specific signal conditioning
-High-accuracy pressure measurement
-Temperature stability
Application
The pressure sensing element CCPS32 detects the applied pressure and converts them into a pressure proportional voltage signal.
There are several different versions available for measuring absolute pressure and gauge pressure. Absolute pressure ranges 100mbar to 70bar are available as standard.
Constant quality in series production at a high level-this claimis accomplished through quality planning an quality assurance.
In addition, we offer the complete solution for your special application requirements: our offer also includes the design and electrical adaptation of the CCPS32 to your individual requirement.

Technical data
Input
MeasuringrangesGaugepressure
Gaugepressureranges Max.permissibleoverload
-2.5......2.5Kpa 250Kpa
0......5Kpa -30Kpa/400Kpa
0......10Kpa -30Kpa/400Kpa
-10......10Kpa 600Kpa
0......20Kpa 600Kpa
-20......20Kpa 600Kpa
0......40Kpa 600Kpa
0......100Kpa 1Mpa
-40......100Kpa 1Mpa
-100......100Kpa 1Mpa
0......200Kpa 1.8Mpa
-100......400Kpa 2.5Mpa
-0.1......1Mpa 4Mpa
-0.1......2Mpa 4Mpa
-0.1......4Mpa 6Mpa
-0.1......7Mpa 10.5Mpa

Output
Outputsignal 0.5V...4.5V
Zero 0.50V±0.05V
Range 4.50V±0.05V
Hysteresis negligible
Characteristics Linear
Conformity(sumoflinearityerror, ≤0.2%ofoutputrange
hysteresisandrepeatability)
Permissibleload ≥10KΩ≥300pF
Risetime Approx.1ms
Switch-ontime Max.10ms
Long-termstability Max.annualerror0.1%ofrange
Absolutepressure
Absolutepressureranges Max.permissibleoverload
0......10Kpa 400Kpa
0......20Kpa 600Kpa
0......100Kpa 1Mpa
0......120Kpa 1Mpa
0......200Kpa 1.8Mpa
0......400Kpa 2.5Mpa
0......500Kpa 2.5Mpa
0......1Mpa 4Mpa
0......2Mpa 4Mpa
0......4Mpa 6Mpa
0......7Mpa 10.5Mpa
Overloadeffect Negligible
Measuredmedia Gasesandfluids,alsoaggressiveandcorrosive,asfaras
compatiblewithaluminiumoxideceramics(99.9%)
Materialswettedbyprocess Diaphragm:99.9%aluminiumoxideceramics(Al2O3)
Powersupply
Supplyvoltage 5VDCstabilized,minimum4.5V/maximum5.5V
Effectofsupplyvoltage Onlinearity Noeffect
Onrangestart Proportional
Onmeasuringrange Proportional
Ontemperaturecompensation Noeffect
Max.Supplycurrent 2mAatavoltagesupplyof4.5V
Typical:<1.5mAatavoltagesupplyof4.5V
Environmentalconditions
Ambienttemperaturerange -40℃...125℃
Processtemperaturerange -40℃...125℃
Compensatedtemperaturerange -20℃...80℃
Storagetemperature -40℃...125℃
Thermalchange
Thermalchangeofthelowerrange-valueinthecompensationtemperaturerange:max.±0.75%ofspan,
withextendedspecification±1%ofspan.
Thermalchangeofoutputspaninthecompensationtemperaturerange:max.±0.5%ofspan.Withmeasuring
ranges≤0.4bar±0.8%ofspan,withextendedspecification±1%ofspan.
